Product Code: BOW9997090

These fuse boxes are suitable for use in automotive and marine applications - each fuse holder is numbered to make fuse installation and identification as easy as possible

On the fuse box is a red LED which illuminates when a fuse has blown, an earth is not required for this the fuse boxes illuminate when they detect a short circuit. This makes it easy to identify blown fuses and makes for easier problem solving (empty fuse holders do not illuminate)

Additional Information:

  • 10-32v
  • 2 Hole Bolt Fixing
  • Holds Mini Blade Fuses (Not Supplied)
  • Transparent High Quality Plastic Cover
  • Side Mounted Spade Connections
  • 1x 5mm Positive Power Input Stud
  • 30amp Max per fuse
  • 100amp Max per box

Dimensions:
35mm (Height) x 85mm (Width) x 95mm (Length)

£11.79 (ex. VAT)

Can only purchase a whole number

10 Way Mini Blade LED Fuse Box
